10/20/30/40A MPPT Solar Charge Controller Dual USB LCD Display 12V 24V Auto Solar Cell Panel Charger Regulator
Details:
Features:
* 12V/24V automatic recognition.
* Built-in overheat/short circuit protection; reverse polarity protection.
* LCD screen one-button to complete the operation of the battery; fully charged; automatic disconnection; automatic memory data storage.
* Double MOS anti-backflow circuit; ultra-low calorific value is automatically restored; no damage to the controller.
* Four-stage mppt regulated charging; high-power multi-phase mppt charging module; high stability; charging efficiency up to 97%; multi-stage charging controller mode; control parameters can be set.
* Suitable for solar power systems; smart homes; solar chargers; solar monitoring systems; solar light boxes; solar billboards; solar warning lights; etc.
Specification:
Name: Solar Controller
Rated charging current: 10A / 20A / 30A / 40A
Solar panel maximum open circuit voltage: 100V (at the lowest temperature); 92V (at the normal temperature of 25°)
System rated voltage: 12V/24V automatic identification
Maximum battery voltage: 8-32V
10A -- Photovoltaic panel maximum input function: 130W(12V); 260W(24V)
20A -- Photovoltaic panel maximum input function: 260W(12V); 520W(24V)
30A -- Photovoltaic panel maximum input function: 390W(12V); 780W(24V)
40A -- Photovoltaic panel maximum input function: 520W(12V); 1040W(24V)
Battery type: sealed lead-acid battery; flooded battery; gel battery; phosphoric acid battery; ternary lithium battery
Equalized charging voltage: maintenance-free lead-acid battery: 14.6V; gel: no; lead-acid flooded battery: 14.8; duration: 2 hours
Absorption charging voltage: maintenance-free lead-acid battery: 14.6V; gel: no; lead-acid flooded battery: 14.8; duration: 2 hours
Float charge voltage: maintenance-free lead-acid battery; gel; lead-acid flooded battery: 13.8V
Low voltage recovery voltage: maintenance-free lead-acid battery; gel; lead-acid flooded battery: 13.8V
Low voltage disconnect voltage: Maintenance-free lead-acid batteries; gel; lead-acid flooded batteries: 13.8V
Static loss: ≤50mA
High voltage protection: lead-acid battery 16V
Light control point voltage: 5V/10V/15V/20V
Temperature compensation coefficient: -4mV/°/2V (25°C)
Discharge circuit pressure drop: ≤0.2V
Display temperature range: -20°C~+70°C
Working environment temperature range: -20℃~+55℃
Storage environment temperature: -30℃~+80℃
Working environment humidity: ≤90% without condensation
Protection class: IP30
Grounding Type: Positive Grounding
30A/40A Installation size: 133*130mm ; Controller Size: 215*145*75mm; Terminal wire diameter: 16mm²/5AWG
10A/20A Installation size: 120*108mm ; Controller Size: 175*120*47mm; Terminal wire diameter: 10mm²/7AWG
Installation hole diameter: 5mm
Packing included:
1 * Solar Controller
Note:
1. Due to manual measurements and slight color variations; please allow 1-3 cm (0.4-1.18 inches) difference to suit different display settings.
2. Due to the light and screen difference; the item's color may be slightly different from the pictures. Please understand.
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
Features:
* 12V/24V automatic recognition.
* Built-in overheat/short circuit protection; reverse polarity protection.
* LCD screen one-button to complete the operation of the battery; fully charged; automatic disconnection; automatic memory data storage.
* Double MOS anti-backflow circuit; ultra-low calorific value is automatically restored; no damage to the controller.
* Four-stage mppt regulated charging; high-power multi-phase mppt charging module; high stability; charging efficiency up to 97%; multi-stage charging controller mode; control parameters can be set.
* Suitable for solar power systems; smart homes; solar chargers; solar monitoring systems; solar light boxes; solar billboards; solar warning lights; etc.
Specification:
Name: Solar Controller
Rated charging current: 10A / 20A / 30A / 40A
Solar panel maximum open circuit voltage: 100V (at the lowest temperature); 92V (at the normal temperature of 25°)
System rated voltage: 12V/24V automatic identification
Maximum battery voltage: 8-32V
10A -- Photovoltaic panel maximum input function: 130W(12V); 260W(24V)
20A -- Photovoltaic panel maximum input function: 260W(12V); 520W(24V)
30A -- Photovoltaic panel maximum input function: 390W(12V); 780W(24V)
40A -- Photovoltaic panel maximum input function: 520W(12V); 1040W(24V)
Battery type: sealed lead-acid battery; flooded battery; gel battery; phosphoric acid battery; ternary lithium battery
Equalized charging voltage: maintenance-free lead-acid battery: 14.6V; gel: no; lead-acid flooded battery: 14.8; duration: 2 hours
Absorption charging voltage: maintenance-free lead-acid battery: 14.6V; gel: no; lead-acid flooded battery: 14.8; duration: 2 hours
Float charge voltage: maintenance-free lead-acid battery; gel; lead-acid flooded battery: 13.8V
Low voltage recovery voltage: maintenance-free lead-acid battery; gel; lead-acid flooded battery: 13.8V
Low voltage disconnect voltage: Maintenance-free lead-acid batteries; gel; lead-acid flooded batteries: 13.8V
Static loss: ≤50mA
High voltage protection: lead-acid battery 16V
Light control point voltage: 5V/10V/15V/20V
Temperature compensation coefficient: -4mV/°/2V (25°C)
Discharge circuit pressure drop: ≤0.2V
Display temperature range: -20°C~+70°C
Working environment temperature range: -20℃~+55℃
Storage environment temperature: -30℃~+80℃
Working environment humidity: ≤90% without condensation
Protection class: IP30
Grounding Type: Positive Grounding
30A/40A Installation size: 133*130mm ; Controller Size: 215*145*75mm; Terminal wire diameter: 16mm²/5AWG
10A/20A Installation size: 120*108mm ; Controller Size: 175*120*47mm; Terminal wire diameter: 10mm²/7AWG
Installation hole diameter: 5mm
Packing included:
1 * Solar Controller
Note:
1. Due to manual measurements and slight color variations; please allow 1-3 cm (0.4-1.18 inches) difference to suit different display settings.
2. Due to the light and screen difference; the item's color may be slightly different from the pictures. Please understand.
